AgfaREF: TECH202604b114
CTP Agfa Avalon LF | 2006
Available Now2006used
Technical Specifications
Category
Pre-Press
Brand
Agfa
Model
CTP Agfa Avalon LF
Year
2006
Location
L'Isère, France
Technical Specifications
| Model | CTP Agfa Avalon LF |
| Max Sheet Size | 116 x 82 cm (45 x 32 inch) |
| Dimensions | 2.45 m x 1.35 m x 1.45 m |
| Weight | 1150.00 kg |
Description
Configuration: Thermal CTP (External Drum).
Year: 2006.
Plate Type: Thermal aluminum plates (830 nm).
Max plate size: 82 x 116 cm (32.2 x 45.6 inches).
Min plate size: 45 x 37 cm.
Resolution: 1200 to 2400 dpi (standard) or 3000 dpi (optional).
Productivity: 8 to 20 plates per hour (depending on the imaging head: Silver, Gold, or XT).
Loading system: Manual loading, semi-automatic, or fully automatic (Autoloader/Multi-cassette).
Laser type: Multi-channel infrared laser diode (GLV technology in some models).
Plate thickness: 0.15 mm to 0.30 mm.
Internal punch: Optional.
Workflow interface: Usually paired with Agfa Apogee.
Total weight: approximately 1,150 kg (main engine only).
Machine dimensions (L x W x H): 2.45 m x 1.35 m x 1.45 m.
Power consumption: approximately 3.0 kW to 4.5 kW.
Year: 2006.
Plate Type: Thermal aluminum plates (830 nm).
Max plate size: 82 x 116 cm (32.2 x 45.6 inches).
Min plate size: 45 x 37 cm.
Resolution: 1200 to 2400 dpi (standard) or 3000 dpi (optional).
Productivity: 8 to 20 plates per hour (depending on the imaging head: Silver, Gold, or XT).
Loading system: Manual loading, semi-automatic, or fully automatic (Autoloader/Multi-cassette).
Laser type: Multi-channel infrared laser diode (GLV technology in some models).
Plate thickness: 0.15 mm to 0.30 mm.
Internal punch: Optional.
Workflow interface: Usually paired with Agfa Apogee.
Total weight: approximately 1,150 kg (main engine only).
Machine dimensions (L x W x H): 2.45 m x 1.35 m x 1.45 m.
Power consumption: approximately 3.0 kW to 4.5 kW.
