DuploREF: TECH20260464d7
Duplo Binder DB 280 | 2010
Available Now2010used
Spécifications Techniques
Catégorie
Post-Press
Marque
Duplo
Modèle
Duplo Binder DB 280
Année
2010
Emplacement
L'Isère, France
Spécifications Techniques
| Modèle | Duplo Binder DB 280 |
| Format Max Feuille | 40 x 32 cm (15 x 12 inch) |
| Vitesse d'Impression Max | 200 cycles / hour |
| Dimensions | 1.27 m x 0.56 m x 0.47 m |
| Poids | 116.00 kg |
Description
Configuration: Single-clamp semi-automatic perfect binder.
Year: 2010.
Binding type: Padding, tape binding, and perfect binding (wraparound cover).
Max book size: 32 x 40 cm (12.6 x 15.75 inches).
Min book size: 8 x 5 cm (3.15 x 1.97 inches).
Max binding thickness: 4 cm (1.57 inches).
Min binding thickness: 0.1 cm (0.04 inches).
Max cover size: 32 x 84 cm.
Glue type: Hot-melt EVA glue (side glue and spine glue).
Warm-up time: Approximately 20 - 25 minutes.
Milling: Integrated roughing blade (notched milling) for better glue penetration.
Nipping: Automated nipping table for square spines.
Max speed: Up to 200 cycles / hour (depending on operator speed).
Total weight: approximately 116 kg (255 lbs).
Machine dimensions (L x W x H): 1.27 m x 0.56 m x 0.47 m.
Power consumption: approximately 1.5 kW.
Power supply: Single phase (110V or 220V/240V).
Year: 2010.
Binding type: Padding, tape binding, and perfect binding (wraparound cover).
Max book size: 32 x 40 cm (12.6 x 15.75 inches).
Min book size: 8 x 5 cm (3.15 x 1.97 inches).
Max binding thickness: 4 cm (1.57 inches).
Min binding thickness: 0.1 cm (0.04 inches).
Max cover size: 32 x 84 cm.
Glue type: Hot-melt EVA glue (side glue and spine glue).
Warm-up time: Approximately 20 - 25 minutes.
Milling: Integrated roughing blade (notched milling) for better glue penetration.
Nipping: Automated nipping table for square spines.
Max speed: Up to 200 cycles / hour (depending on operator speed).
Total weight: approximately 116 kg (255 lbs).
Machine dimensions (L x W x H): 1.27 m x 0.56 m x 0.47 m.
Power consumption: approximately 1.5 kW.
Power supply: Single phase (110V or 220V/240V).
