RapidexREF: TECH202604558f
Rapidex Stitcher 476 | 1970s
Available Now1970used
Spécifications Techniques
Catégorie
Post-Press
Marque
Rapidex
Modèle
Rapidex Stitcher 476
Année
1970
Emplacement
L'Isère, France
Spécifications Techniques
| Modèle | Rapidex Stitcher 476 |
| Vitesse d'Impression Max | 180 to 200 stitches / minute |
| Dimensions | 0.85 m x 0.70 m x 1.55 m |
| Poids | 240.00 kg |
Description
Configuration: Single-head wire stitching machine.
Year: Estimated early to mid-1970s.
Stitching capacity (thickness): 0.2 mm to 25 mm (for block stitching) or up to 30 mm (for saddle stitching depending on the wire used).
Stitching types: Flat and saddle stitching with a tilting table.
Wire types: Round wire (No. 20 to 28) or flat wire (No. I to VI).
Crown width: 14 mm.
Staple leg length: Adjustable to accommodate the thickness of the stack.
Max speed: Approximately 180 to 200 stitches / minute.
Operation: Foot pedal activated mechanical clutch.
Total weight: approximately 240 kg.
Machine dimensions (L x W x H): 0.85 m x 0.70 m x 1.55 m.
Power consumption: approximately 0.75 kW.
Power supply: Usually 3-phase 380V/400V.
Year: Estimated early to mid-1970s.
Stitching capacity (thickness): 0.2 mm to 25 mm (for block stitching) or up to 30 mm (for saddle stitching depending on the wire used).
Stitching types: Flat and saddle stitching with a tilting table.
Wire types: Round wire (No. 20 to 28) or flat wire (No. I to VI).
Crown width: 14 mm.
Staple leg length: Adjustable to accommodate the thickness of the stack.
Max speed: Approximately 180 to 200 stitches / minute.
Operation: Foot pedal activated mechanical clutch.
Total weight: approximately 240 kg.
Machine dimensions (L x W x H): 0.85 m x 0.70 m x 1.55 m.
Power consumption: approximately 0.75 kW.
Power supply: Usually 3-phase 380V/400V.
