PolarREF: TECH202604d82d
Polar 76 EM | 1995
Sold1995used
Technical Specifications
| Model | Polar 76 EM |
| Max Sheet Size | 76 x 76 cm (29 x 29 inch) |
| Max Printing Speed | 45 cycles / minute |
| Dimensions | 1.52 m x 1.75 m x 1.40 m |
| Weight | 1100.00 kg |
Description
Configuration: Programmable hydraulic paper cutter.
Year: 1995.
Cutting width: 76 cm.
Feeding depth: 76 cm.
Feeding height (pile height): 11 cm.
Clamp pressure: Minimum 150 daN / Maximum 2,500 daN.
Control system: EM model with digital display and memory for 99 programs.
Safety features: Infrared light barriers and dual-hand safety start.
Backgauge speed: 20 cm / second.
Smallest cut without false plate: 1.5 cm.
Smallest cut with false plate: 5.0 cm.
Table type: Air bed main table (often with side tables).
Knife speed: 45 cycles / minute.
Total weight: approximately 1,100 kg.
Machine dimensions (L x W x H): 1.52 m x 1.75 m x 1.40 m.
Power consumption: approximately 2.4 kW.
Power supply: 3-phase 380V/400V.
Year: 1995.
Cutting width: 76 cm.
Feeding depth: 76 cm.
Feeding height (pile height): 11 cm.
Clamp pressure: Minimum 150 daN / Maximum 2,500 daN.
Control system: EM model with digital display and memory for 99 programs.
Safety features: Infrared light barriers and dual-hand safety start.
Backgauge speed: 20 cm / second.
Smallest cut without false plate: 1.5 cm.
Smallest cut with false plate: 5.0 cm.
Table type: Air bed main table (often with side tables).
Knife speed: 45 cycles / minute.
Total weight: approximately 1,100 kg.
Machine dimensions (L x W x H): 1.52 m x 1.75 m x 1.40 m.
Power consumption: approximately 2.4 kW.
Power supply: 3-phase 380V/400V.
