MGIREF: TECH202604a2c0
MGI Jet Varnish 2D 3D Foil | 2017
Available Now2017used
Technical Specifications
Category
Packaging
Brand
MGI
Model
MGI Jet Varnish 2D 3D Foil
Year
2017
Location
L'Isère, France
Technical Specifications
| Model | MGI Jet Varnish 2D 3D Foil |
| Max Sheet Size | 105 x 52 cm (41 x 20 inch) |
| Max Printing Speed | 3,000 B2 sheets / hour in varnish mode; up to 1,700 sheets / hour with foil applications |
| Dimensions | 5.50 m x 1.80 m x 1.90 m |
| Weight | 4500.00 kg |
Description
Configuration: Digital UV spot varnishing and hot foil embossing system (2D / 3D digital embellishment press).
Year: 2017.
Max paper size: 52 x 105 cm (20 x 41 inches).
Min paper size: 21 x 29.7 cm (A4 format).
Max printing / varnishing width: approximately 51 cm.
Technology: UV inkjet Drop-on-Demand (DoD) piezoelectric printhead technology.
Printing modes: 2D flat spot UV, 3D raised varnish, and digital hot foil stamping.
Varnish thickness: from 3 microns up to 200 microns for tactile 3D effects.
Inking / coating system: Single-pass UV varnish application with dual varnish tanks and independent circuits.
Foiling system: Inline digital hot foil module (iFOIL) without dies or plates.
Max speed: up to 3,000 B2 sheets / hour in varnish mode; up to 1,700 sheets / hour with foil applications.
Registration: AI-assisted automatic sheet registration with SmartScanner technology and real-time correction.
Feeding system: High-capacity automatic feeder with suction transport and double-sheet detection.
Delivery capacity: High pile stacker with instant UV-cured sheet delivery.
Substrate thickness: from 135 gsm up to 600 gsm (depending on substrate type).
Compatible substrates: Coated paper, laminated stock, plastics, PVC, synthetic media, offset and digital printed sheets.
Applications: Luxury packaging, business cards, book covers, brochures, labels, invitations, and premium marketing materials.
Drying system: Integrated UV curing system with instant drying.
Control system: Touchscreen digital workflow interface with variable data capability.
Total weight: approximately 4,000–4,500 kg depending on configuration.
Machine dimensions (L x W x H): approximately 5.50 m x 1.80 m x 1.90 m.
Power consumption: approximately 12 kW to 18 kW.
Year: 2017.
Max paper size: 52 x 105 cm (20 x 41 inches).
Min paper size: 21 x 29.7 cm (A4 format).
Max printing / varnishing width: approximately 51 cm.
Technology: UV inkjet Drop-on-Demand (DoD) piezoelectric printhead technology.
Printing modes: 2D flat spot UV, 3D raised varnish, and digital hot foil stamping.
Varnish thickness: from 3 microns up to 200 microns for tactile 3D effects.
Inking / coating system: Single-pass UV varnish application with dual varnish tanks and independent circuits.
Foiling system: Inline digital hot foil module (iFOIL) without dies or plates.
Max speed: up to 3,000 B2 sheets / hour in varnish mode; up to 1,700 sheets / hour with foil applications.
Registration: AI-assisted automatic sheet registration with SmartScanner technology and real-time correction.
Feeding system: High-capacity automatic feeder with suction transport and double-sheet detection.
Delivery capacity: High pile stacker with instant UV-cured sheet delivery.
Substrate thickness: from 135 gsm up to 600 gsm (depending on substrate type).
Compatible substrates: Coated paper, laminated stock, plastics, PVC, synthetic media, offset and digital printed sheets.
Applications: Luxury packaging, business cards, book covers, brochures, labels, invitations, and premium marketing materials.
Drying system: Integrated UV curing system with instant drying.
Control system: Touchscreen digital workflow interface with variable data capability.
Total weight: approximately 4,000–4,500 kg depending on configuration.
Machine dimensions (L x W x H): approximately 5.50 m x 1.80 m x 1.90 m.
Power consumption: approximately 12 kW to 18 kW.
