HeidelbergREF: TECH20260435bd
Heidelberg SORK Z | 1973.
Available Now1973used
Spécifications Techniques
Catégorie
Offset Printing Presses
Marque
Heidelberg
Modèle
Heidelberg SORK Z
Année
1973
Couleurs d'Impression
2 Colors
Emplacement
L'Isère, France
Spécifications Techniques
| Modèle | Heidelberg SORK Z |
| Format Max Feuille | 48 x 65 cm (19 x 25.5 inches) |
| Vitesse d'Impression Max | 10,000 sheets / hour |
| Dimensions | 3.63 m x 2.25 m x 2.14 m |
| Poids | 7520.00 kg |
Description
Configuration: Two-color sheetfed offset printing press (S-Line series).
Year: 1973.
Max paper size: 48 x 65 cm (18.9 x 25.6 inches).
Min paper size: approximately 28 x 28 cm.
Max printing size: 46.4 x 64.5 cm.
Printing system: Two-color sheetfed offset lithographic printing system.
Inking system: Multiple oscillating ink distribution rollers with conventional dampening system.
Plate system: Metal offset plates with quick-action plate clamps.
Plate size: approximately 55 x 65 cm.
Blanket size: approximately 56 x 68 cm.
Max speed: up to 10,000 sheets / hour.
Dampening system: Conventional dampening system with optional Alcolor / Epic-Delta configuration.
Feeder type: Automatic sheet feeder with mechanical gripper transport system.
Delivery system: High pile sheet delivery with anti-marking system compatibility.
Drying system: Optional IR dryer and powder spray system depending on configuration.
Registration: High-precision mechanical side lays and gripper alignment system.
Applications: Commercial offset printing, brochures, flyers, stationery, packaging, and marketing materials.
Control system: Electromechanical operator control panel with manual press adjustments.
Machine dimensions (L x W x H): approximately 3.63 m x 2.25 m x 2.14 m.
Total weight: approximately 6,500–7,520 kg depending on configuration.
Power consumption: approximately 11–15 kW (three-phase industrial supply).
Year: 1973.
Max paper size: 48 x 65 cm (18.9 x 25.6 inches).
Min paper size: approximately 28 x 28 cm.
Max printing size: 46.4 x 64.5 cm.
Printing system: Two-color sheetfed offset lithographic printing system.
Inking system: Multiple oscillating ink distribution rollers with conventional dampening system.
Plate system: Metal offset plates with quick-action plate clamps.
Plate size: approximately 55 x 65 cm.
Blanket size: approximately 56 x 68 cm.
Max speed: up to 10,000 sheets / hour.
Dampening system: Conventional dampening system with optional Alcolor / Epic-Delta configuration.
Feeder type: Automatic sheet feeder with mechanical gripper transport system.
Delivery system: High pile sheet delivery with anti-marking system compatibility.
Drying system: Optional IR dryer and powder spray system depending on configuration.
Registration: High-precision mechanical side lays and gripper alignment system.
Applications: Commercial offset printing, brochures, flyers, stationery, packaging, and marketing materials.
Control system: Electromechanical operator control panel with manual press adjustments.
Machine dimensions (L x W x H): approximately 3.63 m x 2.25 m x 2.14 m.
Total weight: approximately 6,500–7,520 kg depending on configuration.
Power consumption: approximately 11–15 kW (three-phase industrial supply).
