PolarREF: TECH202605f76f
Polar 78 ES | 1998
Available Now1998used
Spécifications Techniques
Catégorie
Guillotine
Marque
Polar
Modèle
Polar 78 ES
Année
1998
Emplacement
L'Isère, France
Spécifications Techniques
| Modèle | Polar 78 ES |
| Vitesse d'Impression Max | 45 cycles / minute |
| Dimensions | 1.58 m x 1.95 m x 1.45 m |
| Poids | 1300.00 kg |
Description
Configuration: Programmable hydraulic paper cutter.
Year: 1998.
Cutting width: 78 cm.
Feeding depth: 78 cm.
Feeding height (pile height): 12 cm.
Clamp pressure: Minimum 150 daN / Maximum 3,000 daN.
Control system: ES model with a large monochrome display and programmable memory for up to 99 programs (including repeat and eject functions).
Safety features: Infrared light barriers, two-hand operation, and mechanical safety bolt.
Backgauge speed: 30 cm / second.
Smallest cut without false plate: 2.0 cm.
Smallest cut with false plate: 7.0 cm.
Table type: Nickel-plated air table (main and side tables).
Knife speed: 45 cycles / minute.
Total weight: approximately 1,300 kg.
Machine dimensions (L x W x H): 1.58 m x 1.95 m x 1.45 m.
Power consumption: approximately 3.0 kW.
Power supply: 3-phase 380V/400V.
Year: 1998.
Cutting width: 78 cm.
Feeding depth: 78 cm.
Feeding height (pile height): 12 cm.
Clamp pressure: Minimum 150 daN / Maximum 3,000 daN.
Control system: ES model with a large monochrome display and programmable memory for up to 99 programs (including repeat and eject functions).
Safety features: Infrared light barriers, two-hand operation, and mechanical safety bolt.
Backgauge speed: 30 cm / second.
Smallest cut without false plate: 2.0 cm.
Smallest cut with false plate: 7.0 cm.
Table type: Nickel-plated air table (main and side tables).
Knife speed: 45 cycles / minute.
Total weight: approximately 1,300 kg.
Machine dimensions (L x W x H): 1.58 m x 1.95 m x 1.45 m.
Power consumption: approximately 3.0 kW.
Power supply: 3-phase 380V/400V.
