Man RolandREF: TECH2026056fa3
Roland 200 | Unkn.
Available Nowused
Spécifications Techniques
| Modèle | Roland 200 |
| Format Max Feuille | 520 x 740 mm (20.5 x 29.1 inches) |
| Vitesse d'Impression Max | 13,000 sheets / hour |
| Dimensions | 5.4 m x 2.9 m |
| Poids | 20000.00 kg |
Description
Configuration: Multi-color sheetfed offset printing press.
Model: MAN Roland 200 (R202 / R204 depending on configuration).
Year: Produced from late 1980s to early 2000s.
Machine type: B2-format offset printing press for commercial printing.
Number of colors: 2 to 6 units (commonly 2-color or 4-color configurations).
Max paper size: 520 x 740 mm (20.5 x 29.1 inches).
Max printing area: approximately 510 x 735 mm.
Paper thickness range: 0.04 mm up to 0.80 mm.
Printing system: Sheetfed offset lithographic printing system.
Inking system: RCI (Roland Color Interface) remote-controlled inking system.
Dampening system: Continuous dampening system with integrated control.
Cylinder configuration: Double-diameter impression and transfer cylinders for stable sheet transport and high register accuracy.
Max speed:
Up to 12,000 sheets / hour (early versions)
Up to 13,000 sheets / hour (later versions).
Feeder type: High-performance suction feeder with double-sheet detection.
Delivery system: High pile delivery (up to approx. 900 mm pile height).
Registration system: Remote-controlled register adjustment with high precision.
Automation features:
Remote color control (RCI system)
Job memory and presetting via JobCard
Programmable ink control
Automatic plate change support (on some configurations)
Optional blanket washing system.
Drying system:
Powder spray standard
Optional coating unit (InlineCoater)
Optional UV / IR drying systems.
Applications:
Commercial printing (flyers, brochures, catalogs)
Packaging and carton printing
Stationery and general print production.
Machine dimensions (approx.): 5.4 m x 2.9 m (compact footprint for its class).
Total weight: approximately 12,000 – 20,000 kg depending on configuration.
Power supply: 380–400V industrial supply.
Power consumption: approximately 15–30 kW depending on number of units and options.
Model: MAN Roland 200 (R202 / R204 depending on configuration).
Year: Produced from late 1980s to early 2000s.
Machine type: B2-format offset printing press for commercial printing.
Number of colors: 2 to 6 units (commonly 2-color or 4-color configurations).
Max paper size: 520 x 740 mm (20.5 x 29.1 inches).
Max printing area: approximately 510 x 735 mm.
Paper thickness range: 0.04 mm up to 0.80 mm.
Printing system: Sheetfed offset lithographic printing system.
Inking system: RCI (Roland Color Interface) remote-controlled inking system.
Dampening system: Continuous dampening system with integrated control.
Cylinder configuration: Double-diameter impression and transfer cylinders for stable sheet transport and high register accuracy.
Max speed:
Up to 12,000 sheets / hour (early versions)
Up to 13,000 sheets / hour (later versions).
Feeder type: High-performance suction feeder with double-sheet detection.
Delivery system: High pile delivery (up to approx. 900 mm pile height).
Registration system: Remote-controlled register adjustment with high precision.
Automation features:
Remote color control (RCI system)
Job memory and presetting via JobCard
Programmable ink control
Automatic plate change support (on some configurations)
Optional blanket washing system.
Drying system:
Powder spray standard
Optional coating unit (InlineCoater)
Optional UV / IR drying systems.
Applications:
Commercial printing (flyers, brochures, catalogs)
Packaging and carton printing
Stationery and general print production.
Machine dimensions (approx.): 5.4 m x 2.9 m (compact footprint for its class).
Total weight: approximately 12,000 – 20,000 kg depending on configuration.
Power supply: 380–400V industrial supply.
Power consumption: approximately 15–30 kW depending on number of units and options.
